CINCINATTI SENTINEL TM I28
-
The Sentinel I28 is the world’s most advanced multi-functional test instrument on the market.
-
The I28 features a standard valve manifold design tested with over 40,000,000 cycles.
Advanced Product Features
-
Wall mount configuration 12” W x 9.25” H x 8.75” D
-
Powerful 32-bit processor & 24 –bit A/D converter
-
Language neutral color LCD 12 line 480 x 272 operator display
-
XY Graphing (pressure, loss, or flow)-English, Chinese, Korean, Spanish
-
Indicator Light bar identifies test status Pass/Fail/In-test
-
Barcode ready input RS232 Alpha-numeric string stored with test result.
-
Modular pneumatic and control packages
-
Single test channel
-
|
Multi-test Configurable for Pressure Decay
-
Pressure/Vacuum decay-pressure change
-
Pressure/Vacuum decay-with certified mass flow leak standard
-
Pressure/Vacuum decay-pressure change/time
-
Occlusion test (vacuum or pressure test)
-
Mass flow direct flow reading (pressure test only)Presión.
Selectable Test Units of Measure
Pressure
àPSIG, PSIV, inH2O, cmH2O, mmH2O, kg/cm2, ATM, inHg, cmHg, mmHg, kPa, Pa, MPa, Bar, mBar, Torr
Flow
àSccm, sccs, scch, slpm, slps, slph, scfm, scfs, scfh cm3/min, cm3/segundo, cm3/hora, litros/minuto, litros/segundo, litros/hora, scfm, scfs, scfh
Time
Seg., mseg., min. |
